FDWS86380-F085 Mosfet IC Circuit Chip N-CH 80V 50A POWER56

Name: FDWS86380F085 Mosfet IC Circuit Chip NCH 80V 50A POWER56
Brand: original
Price: 1 USD

Brand Name : original

Model Number : FDWS86380-F085

Certification : original

Place of Origin : original

MOQ : 1

Price : negotiation

Payment Terms : T/T, L/C

Supply Ability : 100,000

Delivery Time : 1-3working days

Packaging Details : carton box

Product Status : Active

Core Processor : N-Channel

Technology : MOSFET (Metal Oxide)

Drain to Source Voltage (Vdss) : 80 V

Current - Continuous Drain (Id) @ 25°C : 50A (Tc)USART

Drive Voltage (Max Rds On, Min Rds On) : 10V

Rds On (Max) @ Id, Vgs : 13.4mOhm @ 50A, 10V

Vgs(th) (Max) @ Id : 4V @ 250µA

Contact Now

FDWS86380-F085 General Purpose Relays Mosfet N-Ch 80v 50a Power56

N-Channel 80 V 50A (Tc) 75W (Tj) Surface Mount Power56

Specifications of FDWS86380-F085

TYPE	DESCRIPTION
Category	Discrete Semiconductor Products
	Transistors
	FETs, MOSFETs
	Single FETs, MOSFETs
Mfr	onsemi
Series	Automotive, AEC-Q101, PowerTrench®
Package	Tape & Reel (TR)
Package	Cut Tape (CT)
Product Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80 V
Current - Continuous Drain (Id) @ 25°C	50A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	13.4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	30 nC @ 10 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	1440 pF @ 40 V
FET Feature	-
Power Dissipation (Max)	75W (Tj)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	Power56
Package / Case	8-PowerTDFN
Base Product Number	FDWS86380

Features of FDWS86380-F085

• Typ RDS(on) = 11.3 m at VGS = 10 V; ID = 50 A

• Typ Qg(tot) = 20 nC at VGS = 10 V; ID = 50 A

• UIS Capability

• Wettable Flanks for Automatic Optical Inspection (AOI)

• AEC−Q101 Qualified and PPAP Capable

• This Device is Pb−Free, Halogen Free/BFR Free and is RoHS Compliant

Applications of FDWS86380-F085

• Automotive Engine Control

• PowerTrain Management

• Solenoid and Motor Drivers

• Electronic Steering

• Integrated Starter/Alternator

• Distributed Power Architectures and VRM

• Primary Switch for 12 V Systems

Environmental & Export Classifications of FDWS86380-F085

ATTRIBUTE	DESCRIPTION
RoHS Status	ROHS3 Compliant
Moisture Sensitivity Level (MSL)	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095

Product Tags:

FDWS86380-F085

Mosfet IC Circuit Chip

N-CH 80V 50A POWER56
